Manually operated 3way T shaped port type ball valve
*The pictures and drawings in this website are only for references.Please contact our sales department for the details.
| Product Code | E307N-T3 |
|---|---|
| Operation | Manual operated(Lever type) |
| Body Material | Stainless steel(SCS13) |
| Lining Material | - |
| Balldisk Material | SCS13A,14A,16A |
| Diaphragm/Seat Material | PTFE, Reinforced PTFE |
| Range Of Nominal Diameter | 125〜200 |
| End Connection | Flange(JIS 10K) |
| Remarks | - |
